Features
Fully-featured analog mastering console
Fully transparent signal path
INPUT SECTION
Four selectable analog inputs
Separate phase inverts for left and right
Low-cut and high-cut filters with 12 / 24 dB/oct slopes
Separate input gain controls for left and right
TRANSFER SECTION
Six fully bypassable insert points with powerful functions:
MS for inserts 1 – 2
Swap for inserts 2 – 3 and 4 – 5
Parallel for insert 3
Insert 6 can be moved to post output
Image processor with stereo width control and elliptic filtering capability
Gain and bypassable master fader
MONITOR SECTION
Four external monitor sources
Total of 12 monitor selectors
2 monitor outputs
Four monitoring modes:
Stereo
Mono
Swap LR
Side (Mono)
Monitor offset (configurable for any monitor source)
Digitally controlled monitor volume with a 47-position rotary switch
-15 dB DIM button
Class-A headphone amplifier with an individual volume control
Meter output featuring a separate -6 dB pad
Separate activation for both channel outputs
Overview
Knif Mastering Controller is an audio mastering console featuring a vast array of processing and routing options for commanding the whole mastering chain. The console is built using state-of-the-art components and the result is a unit with unparalleled transparency and flexibility.
The controller features Elma® rotary controls and high-quality push buttons manufactured in Japan. The buttons are illuminated with a sophisticated touch and a nice low volume “click”.
The controller can be equipped with a built-in AES/EBU router for selecting between a multitude of digital sources, thus narrowing down the amount of DAC channels required.
As default, the unit operates with an external power supply but also an analog 2U metering bridge with a built-in power supply is available.
Mastering Controllers are exclusively built to order.
Downloads
Pricing and options
Stereo version, basic
9500 €
2 × 2-channel mastering edition
Ask for price
OPTIONS
AES/EBU router
+500€
Metering bridge (2U)
+800 €
12-channel monitoring (single input)
Ask for price
All prices excluding VAT, duties and shipping costs
Tech specs
INPUT SECTION
Input impedance
10 kΩ
Output Impedance
Balanced, non-floating
44 Ω
Maximum Input Level
Active On
+29.7 dBu
Gain Range
-5.5 … +11.5 dB
Frequency
in 24 dB/oct mode refers to -6 dB point
Slope
High-Pass Filter
15 … 48 Hz
12 / 24 dB/oct
Low-Pass Filter
13 … 25 kHz
12 / 24 dB/oct
Number Of Inputs
4 x Analog (+ 2 x digital routing with AES/EBU option)
TRANSFER SECTION
Number Of Inserts
6
Parallel Mix Range
-26 … 0 dB
Transfer Out, Output Impedance
Balanced, non-floating
44 Ω
Elliptic Filter Range
6 dB/oct
50 … 270 Hz
Frequency Response, Input + Transfer, Active On
1 dB, Ref. 1 kHz
<1 Hz … 150 kHz
Frequency Response, Input + Transfer, Active, Fader, Parallel & Image ON
1 dB, Ref. 1 kHz
<1 Hz … 100 kHz
Crosstalk, Active, Fader & Parallel On
1 kHz
10 kHz
10 kHz, Worst Case
-102 dB
-82 dB
-79 dB
Noise
(Input + Transfer)
Unweighted
A-Weighted
-97 dBu
-100 dBu
Noise (Input + Transfer, insert MS ON)
Unweighted
A-Weighted
-93 dBu
-97 dBu
Dynamic Range (Input + Transfer)
Typical
125 dB
±3.5 dB
S Level Range
±5.5 dB
Gain Range
MONITOR SECTION
Input Impedance
Balanced, Buffered
10 kΩ
Output Impedance
Quasi-balanced
100 Ω
Maximum Input Level
Balanced
+28 dBu
Frequency Response
-1 dB, 1 kHz ref.
<1 Hz … 200 kHz
Monitor Offset Range
-5.5 … +15.5 dB
Monitor Volume Range
-30 … +23 dB
THD + Noise, 20 dBu Input
1 kHz
10 kHz
0.0005%
0.004%
Noise
Typical
Worst Case
-105 dBu
-100 dBu
Crosstalk
1 kHz
10 kHz
-90 dB
-70 dB
Load
Max. Level
THD+N, 10 kHz
Phones
600 Ω
47 Ω
+22 dBu
+14 dBu
0.001%
0.001%
Minimum Recommended Load Impedance
20 Ω
Section Gain
Volume @ 0 dB
-23 dB
MAINS
Mains Voltage
115 / 230 VAC, selectable
Mains Frequency
50 / 60 Hz
Power Consumption
59 W
GENERAL
MASTERING CONTROLLER
Dimensions
w x l x h
430 x 352 x 176 mm (4U)
Weight
10.9 kg
Connectors
Signal
Power
XLR, Neutrik, 3-pin, gold-plated
XLR, Neutrik, 7-pin, gold-plated
POWER SUPPLY
Dimensions
w x l x h
275 x 175 x 90 mm
Weight
3.4 kg
Connectors
Power Out
Power Out
Mains
XLR, Neutrik, 7-pin, gold-plated
XLR, Neutrik, 4-pin, gold-plated
IEC, C13
METERING BRIDGE
Dimensions
w x l x h
430 x 352 x 88 mm (2U)
Weight
7.0 kg
Connectors
Signal
Power Out
Mains
XLR, Neutrik, 3-pin, gold-plated
XLR, Neutrik, 7-pin, gold-plated
IEC, C13
CONTENT
Mastering Controller
1 pcs
Power Supply or Metering Bridge
1 pcs
Mastering Controller Power Cord, XLR 7-pin. approx. 180 cm
1 pcs
WARRANTY
2 years (for terms and conditions, refer to the Warranty section)
